Fan Capacity
Fan mounts offer space for two 140mm fans on the front panel and two 120mm fans on the top panel.
Radiator Capacity
The top panel offers space for a 240mm radiator and the front panel provides room for a 280mm radiator.
Lights. CAM. Action.
NZXT CAM is your go-to software for personalizing the look and performance of your build.
| Dimensions | W: 464 mm H: 227 mm D: 446 mm |
| Material(s) | SGCC Steel, Tempered Glass |
| Weight | 7.01 kg |
| Clearance | Max CPU Cooler Clearance:Up to 165mm Max GPU Clearance:Up to 365mm Front Radiator Clearance:45mm Cable Management:Up to 23mm |
| Motherboard Support | Mini-ITX, Micro-ATX, ATX, and EATX |
| Front I/O Ports | USB 3.2 Gen 1 Type-A:1 USB 3.2 Gen 2 Type-C:1 Headset Audio Jack:1 |
| Filters | All Air Intakes |
| Expansion Slot | 7 |
| Radiator Support | Front:Up to 280mm Top:Up to 240mm Rear:Up to 120mm |
| Fan Support | Front:2 x 120mm / 2 x 140mm Top:2 x 120mm Rear:1 x F Series Quiet 120mm (Case Version) included Bottom:1 x F Series Quiet 120mm (Case Version) included |
| Fan Specs | Model:F120Q (Case Version) Speed:1200 ± 240RPM Airflow:62.18 CFM Static:1.05 mm - H2O Noise:25.1 dBA Fan Connector:3-pin |
| Model Number | CC-H51FW-01 |
